תיאור
פרטים טכניים :
כללי :
- דגם WR3600H
- אמינות Operating Temperature: 0 ℃ ~ 40 ℃ (32 ℉ ~104 ℉) | Storage Temperature: -40 ℃ ~ 70 ℃ (-40 ℉ ~ 158 ℉) | Humidity: 10% ~ 90% non-condensing | Storage Humidity: 5% ~ 95% non-condensing
מעבד :
- Chipset BCM6764
- פרטי מעבד 2.0 GHz Quad-Core, ARM Cortex-A7
זיכרון/אחסון :
- Flash/ROM 128MB (1 Gbit) NAND
- DDR/RAM 512MB (4 Gbit) DDR3L
אלחוטיות :
- 5GHz Wi-Fi Speed 2882 Mbps
- 2.4GHz Wi-Fi Speed 688 Mbps
- 5GHz Wi-Fi Streams 2T2R (2×2 MIMO)
- 2.4GHz Wi-Fi Streams 2T2R (2×2 MIMO)
- אנטנות WIFI 4× Fixed
- 2.4GHz Antenna Gain Max 5.5dBi
- FEM or PA/LNA 5GHz: 2× External | 2.4GHz: 2× External
- Beamforming
- טווח תפעול 220 מטר
- טווח פעילות בין קירותTwo wooden walls with thickness < 10 cm (4”) One concrete wall with thickness < 20 cm (7”) or two concrete walls with thickness < 10 cm (4” )
ממשקים :
- 2.5Gigabit RJ45 Ports1
- Ethernet Notes The 2.5G port is WAN port, the Gigabit ports are LAN ports
- LED Power, Internet, WAN, LAN, 2.4 GHz Wi-Fi, 5GHz Wi-Fi
- כפתורים WPS, Reset
חשמל :
- ספק כח 12V 1A
- מתאם Input: 100 ~ 240 V, 50/60Hz AC | Output: 12V 1A DC
- מקסימם צריכה 9W
מכני :
- מידות Antenna Length: 175 mm | Device: 183.3×109×38 mm
- משקל 332.0 g
| Model Version | WR3600H 1.0 | |
|---|---|---|
| CPU | Chipset | BCM6764 |
| CPU Details | 2.0 GHz Quad-Core, ARM Cortex-A7 | |
| Memory/Storage | Flash/ROM | 128 MB (1 Gbit) NAND |
| DDR/RAM | 512 MB (4 Gbit) DDR3L | |
| Wireless | 5 GHz Wi-Fi Speed | 2882 Mbps |
| 2.4 GHz Wi-Fi Speed | 688 Mbps | |
| 5 GHz Wi-Fi Streams | 2T2R (2×2 MIMO) | |
| 2.4 GHz Wi-Fi Streams | 2T2R (2×2 MIMO) | |
| Wi-Fi Antennas | 4× Fixed | |
| 5 GHz Antenna Gain Max | 5.5dBi | |
| 2.4 GHz Antenna Gain Max | 5.4dBi | |
| FEM or PA/LNA |
|
|
| Beamforming | True | |
| Range Performance | Max: 220 m (722 ft) Indoor WiFi range varies depending on the layout and wall materials. See Wall Performance spec for placement suggestions. |
|
| Wall Performance | Two wooden walls with thickness < 10 cm (4”) One concrete wall with thickness < 20 cm (7”) or two concrete walls with thickness < 10 cm (4”) |
|
| Interfaces | 2.5G RJ45 Ports | 1 |
| Gigabit RJ45 Ports | 4 | |
| Ethernet Notes | The 2.5G port is WAN port, the Gigabit ports are LAN ports | |
| LED |
|
|
| Physical Buttons |
|
|
| Power Input | DC Jack | |
| Power | Power Methods | DC |
| DC | 12V 1A | |
| Power Adapter | Input: 100 ~ 240 V, 50/60 Hz AC Output: 12V 1A DC |
|
| Max Power Consumption (W) | 10W | |
| Reliability | Environment |
|
| Certifications | FCC, CE | |
| Mechanical | Installation |
|
| Dimension | Device: 183.3×109×38 mm 7.22×4.29×1.5 inches Antenna Length: 175 mm 6.89 inches |
|
| Product Weight | 332.0 g (11.71 oz.) | |
| Package Content |
|
|
| Ordering Information | Retail Package Weight | EU: 762.0 g (26.88 oz.) |
| Retail Package Dimension | 330×256×60 mm 12.99×10.08×2.36 inches |
|
| Units per Carton | 10 | |
| Carton Dimension | 52.8×31.7×34.7 cm 20.79×12.48×13.66 inches |
|
| Carton Gross Weight | EU: 8.5 kg (18.74 lbs) | |
| Carton Net Weight | EU: 7.6 kg (16.76 lbs) | |
*הנתונים לפי אתר היצרן
