echnical Specifications
● Operating standards: IEEE802.3z/AB, 10/100/1000Base-T and 100/1000Base-SX/LX/HX
● MAC address table: 4K
● Data Buffer: 256K
● Connector:
UTP: RJ-45,10/100/1000Mbps;
Fiber: LC,100/1000Mbps
● Cable:
UTP cable: Cat 5e or Cat 6 (the max distance up to 100m)
Fiber: multimode: 50/125, 62.5/125μm (the max distance up to 550/224m)
single mode: 8.3/125, 8.7/125, 9/125μm (the max distance up to 100km)
● Flow control
Full Duplex: IEEE802.3x
Half Duplex: back pressure.
● Power: AC 220V(170-260V) 50Hz; DC 5V, 1A
● Ambient temperature: 0 ~ +50°C
● Storage temperature: -20 ~ +70°C
● Humidity: 5% ~ 90%
● Dimensions: External Power: 26 (high) x 70 (width) x 93 (length) mm
*הנתונים לפי אתר היבואן.
