SPECIFICATIONS
Model
Nominal Voltage 12V
Rated Capacity (10Hr rate) 40Ah
Dimensions
Length Width Height Total Height
197mm (6.54″) 166mm (6.54″) 171mm (6.73″) 171mm (6.73″)
Weight Approx. 12.10KG(26.67lbs) ± 3%
Capacity @25°C (77°F) 20 hour (4.0,10.8V) 10 hour (6.4A,10.5V) 5 Hour ( 10A,10.2V) 1 Hour (24A,9.6V)
40.0Ah 32Ah 30 Ah 24Ah
Internal Resistance Fully charged at 25°C, approx. 8.2mΩ
Max. Discharge Current 400A (5 Sec. )
Capacity Affected by Temp.
(10Hr)
40°C(104°F) 25°C(77°F) 0°C(32°F) ‐15°C(5°F)
102% 100% 85% 65%
Self Discharge Rate
After 3 months Storage After 6 months Storage After 12 months Storage
91% 82% 64%
Charge Method
Cycle Use Float Charging
14.4‐15.0V (Initial current less than 2.10A)
@25°C (77°F)
13.5‐13.8V@25°C (77°F)
*הנתונים לפי אתר היבואן.
