תיאור
Nominal Voltage 12V
Rated Capacity (10Hr rate) 55Ah
Length Width Height Total Height : 230mm (9.06″) 138mm (5.43″) 211mm (8.31″) 229mm (9.027″)
Weight Approx. 16.2KG(35.71lbs) ± 3%
Capacity @25°C (77°F) 20 hour (5.5A,10.8V) 5 hour (8.8A,10.5V) 3 Hour (13.8A,10.2V) 1 Hour (33A,9.6V)
55Ah 44Ah 41.4 Ah 33Ah
Internal Resistance Fully charged at 25°C, approx. 6.5mΩ
Max. Discharge Current 550A (5 Sec. )
Capacity Affected by
Temp.(10Hr)
40°C(104°F) 25°C(77°F) 0°C(32°F) ‐15°C(5°F)
102% 100% 85% 65%
Self Discharge Rate
After 3 months Storage After 6 months Storage After 12 months Storage
91% 82% 64%
Charge Method
Cycle Use Float Charging
14.4‐14.4V (Initial current less than 22A) @25°C (77°F) 13.5‐13.8V@25°C (77°F)
*הנתונים לפי אתר היבואן.
