Specification :
- General
- Product Dimensions (W × H × D)126mm×97mm×42mm
- Package Dimensions (W × H × D)231mm×203mm×51mm
- Net Weight 0.365kg
- Packing List
4G LTE Router × 1
Power Adapter × 1
Ethernet Cable × 1
Quick Start Guide × 1
Regulatory Compliance and Safety Information × 1
- Packing MethodSingle pack
- Working Temperature0 ℃ to 40 ℃ (32 ℉ to 104 ℉)
- Working Humidity10% to 90% RH non-condensing
- Storage Temperature-40 ℃ to 70 ℃ (-40 ℉ to 158 ℉)
- Storage Humidity5% to 90% RH non-condensing
- Installation ModeDesktop installation
- Max. Power Consumption≤ 6 W
- Gross Weight0.396 kg
- Wireless Parameter
- Max. Transmission Rate of Air Interface2.4 GHz: 300 Mbps
- Wireless StandardIEEE 802.11b/g/n @2.4GHz
- Working Frequency Band2.4 GHz
- Transmitting Powerup to 20dBm
- Wireless Performance2*2 MIMO supported
- Receiving Sensitivity
-86±2dBm@N20-MCS0
-66±2dBm@N20-MCS7
-83±2dBm@N40-MCS0
-64±2dBm@N40-MCS7
-92±2dBm@B-1M
-83±2dBm@B-11M
-88±2dBm@G-6M
-71±2dBm@G-54M
- Antenna
2 External 4G/3G Antennas
2 Internal Wi-Fi Antennas
- Network TypeLTE CAT.4
- Mobile StandardsFDD LTE, TDD-LTE,WCDMA
- Mobile BandsFDD-LTE: B1/B3/B5/B7/B8/B20/B28AB TDD-LTE: B38/B40/B41 WCDMA: B1/B5/B8
- 4G SpeedDL: 150 Mbps, Upload: 50 Mbps
- Hardware Parameter
- Network Interface
2 × RJ45, 10/100 Mbps auto-negotiation
1 × Nano SIM Card Slot
- LED Indicator
Internet LED*1
Wi-Fi LED*1
LAN LED*1
4G/3G Signal strength LED*3
- ResetWPS/Reset button*1
- Power Supply Method9 VDC, 0.6 A power adapter power supply
- Power Specifications9 VDC, 0.6 A
- Software Function
- Application Function
3G/4G Route Mode, Wireless Router Mode, and AP Mode supported
DHCP Server supported
Guest Network Configuration supported
Signal Adjustment supported
WiFi Schedule supported
- Security ModeWPA-PSK, WPA2-PSK, WPA and WPA2 supported
- Security MechanismHide SSID
- Management MethodWeb
- UpgradeWeb
- System LogSystem log
*הנתונים לפי אתר היצרן.
